CPM2404
Product Description:
The CP2404 represents the pinnacle of power and efficiency in its series, driven by a robust Weichai 6-cylinder diesel engine rated at 176.5kW (240HP). It features a refined 16F+16R synchronized shuttle shift transmission, complemented by an optional creeper gear for precision low-speed operations. With a substantial structural weight of 7,800kg, it delivers exceptional traction and stability for the most demanding tasks. The advanced wet dual-stage clutch ensures smooth, durable shifting, while the semi-independent PTO (760/850 rpm) provides reliable power for heavy-duty implements such as large square balers, deep rippers, and wide-width disc mowers.
Inquiry Now
- Product Description
- Inquiry Now
- Related Products
- Customer Reviews
Product Description
Model | CP2404 | ||||
Dimensions of Tractor(mm) | Length | 5500mm | |||
Width | 2580mm | ||||
Height (to the exhaust vent) | 3100mm | ||||
Tread | Front Wheel | 1990mm | |||
Rear Wheel | 1700-2380 (usual 1800) | ||||
Axle Base | 2800 | ||||
Min.Ground Clearance | 450 | ||||
Structure weight (kg) | 7800Kg | ||||
Engine | Model | Weichai | |||
Type | Vertical,6-Cylinder,Water Cooled and 4-stroke | ||||
Rated Power(kw) | 176.5kw | ||||
Rated speed (r/min) | 2200 | ||||
Fuel | Diesel | ||||
Tires | Front Wheel | 16.9-28 | |||
Rear Wheel | |||||
Clutch | Wet,Dual-stage clutch | ||||
Steering | Hydraulic steering | ||||
Transmission Type | 16F+16R synchro meshed Shuttle shift/ Creeper gear shift | ||||
Suspension Type | 3-point links | ||||
PTO | Type and Rev | Semi-independent Type 760/850r/m | |||
Spline Size | F38 Rectangle Spline with 6 teeth | ||||
