CPM554
Product Description:
The CPM554 is a compact yet powerful 55HP utility tractor designed for versatility across various agricultural applications. Powered by a reliable 4-cylinder diesel engine, it delivers a rated power of 40.4kW at 2400 rpm. The adjustable tread width (1000–1300mm) allows for optimal configuration depending on row spacing or terrain. Equipped with an 8+2 gearbox and responsive power steering, it ensures ease of operation. The semi-independent PTO (720 rpm, optional 540/720 rpm) and standard 3-point linkage make it fully compatible with a wide range of implements, including rotary tillers, flail mowers, and trailers, making it ideal for small to medium-sized farms.
Inquiry Now
- Product Description
- Inquiry Now
- Related Products
- Customer Reviews
Product Description
Model | CPM554 | ||||
(mm)Dimensions of Tractor | Length (to front ballast) | 3700 | |||
Width | 1600 | ||||
Height (to the exhaust vent) | 2300 | ||||
Tread | Front Wheel | 1250/1000～1300 | |||
Rear Wheel | 1250/1000～1300 | ||||
Axle Base | 1950 | ||||
Min.Ground Clearance | 310 | ||||
Structure weight (kg) | 2003 | ||||
Ballast weight | Front ballast | 56 | |||
Rear ballast | 112 | ||||
Rated traction force (kg) | 663 | ||||
Engine | Model | 4100 | |||
Type | Vertical,4-Cylinder,Water Cooled and 4-stroke | ||||
Rated Power(kw) | 40.4 | ||||
Rated speed (r/min) | 2400 | ||||
Fuel | Diesel | ||||
Tyre | Front Wheel | 6.50-16 or options 7.5-16 | |||
Rear Wheel | 9.5-24 or options 11.2-24 | ||||
Clutch | Single-stage clutch | ||||
Steering | power steering | ||||
Transmission Type | 8+2 shift | ||||
Suspension Type | 3-point links | ||||
PTO | Type and Rev | Semi-independent Type 720r/m or 540/720r/m | |||
Spline Size | F35 Rectangle Spline with 6 teeth | ||||
